Automatic Gyroscopic Mixer GA480
Automatic button
Quick clamping
Simple diagnosis
The GA480 is the fastest automatic mixer on the market with the best performance. The GA480 makes the user’s life easier with the “Auto” button that selects the optimal mixing speed and time depending on the product and its weight. This “Auto” option combined with the best speed, clamping, and dynamic balancing of the equipment, offers the market’s reference mixer.
Read more ≫
- Fully automatic clamping
- Intelligent mixing
- Graphic display
- Dedicated control on the clamping unit
- Dynamic balancing
- Service control via diagnostic software
- Fully removable table for cans
- Multiple speeds up to 230 rpm
- Continuous regulation of rpm and time.
- Built-in loading ramp
- 38 cm diameter of the lower plate.
- Up to 40 kilos; can height 8-40 cm
Technical specifications
General
- Medium and high volume paint rotation.
Cans
- Max. product weight: 40 kg
- Min. height: 80 mm
- Max. height: 400 millimeters
- Plate diameter: 380 mm
- Suitable for oval cans.
- It is possible to mix several cans.
Footprint and weight
- Height: 101 x 82 x 81 (79) cm
- Weight: 240 kilograms
Repositioning
- Automatic and dedicated control.
Usage
- Swinging rotating door (for mounting left or right)
- Optional sliding door
- Fully removable loading plate
- The cradle stops automatically in the unloading position.
- On-screen user interface: automatic button, graphic display, easy to adjust
- Variable speed (soft start), between 230 and 100 rpm, dynamic balancing
Service
- Removable top cover and back panel
- Splash guard to protect against paint spills, replaceable rubber on the lower clamping plate, service control via FFM Maintenance and/or screen, USB port on the outside
- 750-watt AC motor
Installation
- Wheels and feet at the bottom, integrated loading ramp.
- Power supply: 230V-50/60Hz or 115V/60Hz, standard removable power input at the back, power switch on the side
